Tuber - storlekar
Shells - dimensions



Tillbaka | Back





Dimension (mm)
Diameter x length

Tolerance diameter:

Thickness

487.5x 1600

-6.0/0.0 mm

12.7, 14, 15.5 mm

487.5x 2100

-6.0/0.0 mm

12.7, 14, 15.5 mm

487.5x 2200

-6.0/0.0 mm

12.7, 14, 15.5 mm

487.5x 2450

-6.0/0.0 mm

12.7, 14, 15.5 mm

Tolerance length
–1.0/+1.0 mm



Tolerance thickness:
-0.3/0.3 mm


Dimension (mm)
Diameter x length

Tolerance diameter:

Thickness (mm)

174.4 x 1600

-1.2 % - 0.0

12.5, 14, 15.5

177.4 x 1600

-1.2 % - 0.0

12.5

270 x 1600

-1.2 % - 0.0

13, 14

293 x 1600 or 2200

-1.2 % - 0.0

13

324 x 1600 or 2100

-1.2 % - 0.0

12.7

355 x 1600

-1.2 % - 0.0

13

360 x 1600 or 2200

-1.2 % - 0.0

13

366 x 1600 or 2200

-1.2 % - 0.0

13

368 x 1600 or 2200

-1.2 % - 0.0

13

381 x 1600

-1.2 % - 0.0

13

535 x 1600

-1.5 % - 0.0

13, 15.5

559 x 1600

-1.5 % - 0.0

13

562 x 1600

-1.5 % - 0.0

13

647 x 1600

-1.5 % - 0.0

14

Tolerance length
-1.0/+1.0 mm



Tolerance thickness:
-0.3/0.3 mm


Dimension (mm)
Diameter x Thickness x length
300 x 12.5 +12.5 x 1600

Tolerance diameter:
-1.2 % - 0.0

Tolerance length: -1.0/+1.0 mm

Tolerance thickness:
-0.3/0.3 mm
